품상세정보
[하비몬 댓글]
■구성품: 자동차키트(2스피드미션) + 560 모터 / 880 변속기 + 서보 3개(25Kg) + UBEC + LED 라이트세트■별매품: 송수신기(6채널 권장) + 배터리(크기 15.2 x 5.3 x 3.3cm) + 전용 충전기
- 구성품 및 사양은 제조사 사정에 따라 사전 고지 없이 변경 될 수 있음
- 설명에 첨부된 제품 사진은 참조용으로 실제 키트의 구성품과 다를 수 있음
[ BC8 - 플래그십 버전 ]
A Arm Support : Metal CNC (8 Units)
Up & Down A Arm : Metal CNC (16 Units)
Steering Cup Holder : Metal CNC (4 Units)
Steering Cup : Metal CNC (4 Units)
Rear Wheel Support : Metal CNC (4 Units)
Steel 10T And 14T Motor Tooth
Transfer Case : Metal CNC (4 Units)
Axle Housing : Metal CNC (4 Units)
SK-1 Sound System w/Speaker 60mm
Description
Transmission System 560-Size, 38 Turn Brushed Motor
Specifically-designed CrossRC motor with 10-tooth steel pinion gear for maximum performance anddurability
Full metal 2 speed gearbox
2 steering and 1 shift servo
The transmission structure consists of two components of front and rear drive and transmission module
Simulation of giant cross-country mammoth tires in 5.3”
Biaxial steering structure
Double ball CVD semi shaft with hard special steel
Heavy duty fifth-wheel
Features
Completely independent 8-wheel suspension
CNC metal 3mm thick I-beam chassis rails
Four-wheel front steering with torsion spring suspension system
38T, 560-size brushed motor and 10T pinion
All-metal 2-speed gearbox
Flagship version features all-metal main suspension components
Double-ball CV-driveshaft system
Specifications
Overall Length: 765mm
Overall Width: 250mm
Overall Height: 276mm
Wheelbase: 516mm (144, 228, 144mm)
Wheel Tread (Track) : 194mm
Ground Clearance (to axle pumpkin): 57mm
Tire Diameter : 135 x 48mm
Wheels : 2.2"
Important Note!
This Truck Weighs Approx. 11kg
